Ignition Coil 6 Volt Oil Filled (Genuine Lucas 47275OF)

6 Volt Single Output Oil Filled Ignition Coil.

GENUINE Lucas part no. 47275OF / 17M6

As fitted to 6V BSA C11, C12, C15, A50, A65 models, and Triumph Unit models using 6V Systems.

Applications:

• British Single Cylinder motorcycles with 6 volt electrics and points or Sure-Fire/True-Fire electronic ignition system (one coil required)


• British Twin Cylinder motorcycles with 12 volt electrics and Sure-Fire/Altair electronic ignition system (two coils required)

Electrical specification:

Primary resistance: 2 ohms +/- 10%
Secondary resistance: 10 Kohms +/- 10%
Low tension connections: two M5 studs
High tension connection: 7mm female connector

Accesories included: ht outlet cover, four 6.35mm(1/4") male lucar (spade) terminals, two spring washers & two nuts

Dimensions:

Diameter: 1 5/8" (41mm) approx.
Overall length: 4 3/8" (111mm) approx.
Body Length (to flange): 3.3" (84mm) approx.
Flange diameter: 1.9" (48mm) approx.
HT outlet length: 0.55" (14mm) approx.

Weight: 350g (approx.)
