Product Code: ALB
Attachments:
- ALB.pdf

Price: $307.00

Available Options

Plug Lead (HT Lead) Option:
Plug Wire (HT Lead) Option:
Altair Single 12 Volt ~ Ignition Coil Option:
Coil Clamp Option:
Voltage Regulator (alternator) Option:

Is your current ignition not letting your bike reach its full potential?

Need an advance curve that better suits your engine?

Does your bike not want to fully rev out due to poor spark energy?

Is your battery not lasting a full race meeting?

The PAZON Altair ignition system is the hassle-free solution to your ignition worries.

Fits these classic motorcycles:

Enfield Bullet 350/500cc singles: Export, India, Redditch, Sixty 5, Electric Start
12 volt electrics, negative ground (can also be wired for positive ground)

Completely replaces the original points, condenser & mechanical advance.
The result is improved performance, excellent starting, smoother running and low maintenance.

7½ year warranty

Is your engine power limited by your current ignition advance curve?

The Altair ignition incorporates a mapped advance curve that precisely controls the ignition timing throughout the rev range.

Have you found setting the timing on your current ignition system a bit 'hit and miss'?

Timing made easy, with the on-board static timing light. Static timing is set at TDC.

Is your existing ignition system battery-thirsty?

The Altair features active dwell control that maintains the right energy in the ignition coils for optimum performance, whatever the engine rpm.
The intelligent software also means that Altair is highly efficient, drawing little power, extending battery life considerably.

High spark energy and lower power draw, even at low battery voltages.

ALB.pdf

Features
Electronic Advance
Electronic Tacho Output
Low Cranking Speed Performance √√
Low Supply Voltage Performance √√√
Mapped/Programmed Advance
Static Timing Led
Applications
Motorcycle Brands Royal Enfield
Suitable for competition bikes √√
Engine Configuration
Piston(s) Single
Stroke Four Stroke
Specification
Ignition Type Digital
Supply Voltage 12 Volt
